The Hear4You Echo MegaLoop is an exceptional Induction Room Loop System, creately predominantly for TV’s, DVD & HiFi listening in your home, or for people who have a hearing aid with a telecoil “T” setting. This product features an extremely versatile Induction Loop amplifier & sophisticated background noise control.

The Echo MegaLoop takes sound from your TV or other sound source and converts it into a signal, which is fed into a wire fitted in a continuous loop around the edges of the room. This signal can then be picked up by a hearing aid switched onto the ‘T’ setting. The tone and volume can then be adjusted completely independently from that coming out of the TV speaker, providing the best possible listening conditions.

Boasts outstanding sound quality transmitting sound direct to your hearing aid. The greater range of clear undistorted power is almost twice that of previous systems. The improved signal strength allows the hearing aid to work at its optimum with a huge reduction in background noise. A highly active tone control circuit enables unparalleled adjustment of high/low tones.

Product Features

• Standard Room Loop
• Excellent amplification
• Robust & Cost-effective

Product Contents

• Scart Plug
• Phono Phono Lead
• Loop Wire; 38m (with clips)
• Echo MegaLoop™ amplifier
• Microphone on Lead (with Mono Plug)
• Mains Power Adapter; 12V DC min 1.5A

Product Specifications

• Distortion: <1%
• Audio Input: +20dB
• Microphone 1 Input: -20dB
• Microphone ‘P‘ Input: -30dB
• Frequency Response: 100Hz to 5.2khz
• Dimensions: 186 mm W x 50 mm H x 82 mm D
• Tone Control Effect: 20db range max – min (v/c middle)
• Power Supply: 12V DC, min. 1.5 amp (output Positive + Centre)
• Line Input: 2 Line-level Inputs; Phono Connectors, with gain control
• Microphone: 2 Microphone Inputs; 3.5mm mono /electret condenser
• Output: Output Current > 3A peak current; Loop resistance less than 1Ω
• Line Output: 1 Line-level Output; 3.5mm mono, Nominal Level = – 6dBu, output imp. 100ohm
