Amplifier Only (No Cables or Power Adapter are included).

The Hear4You Echo MegaLoop is a superb Induction Room Loop Amplifier, designed for one sole purpose: TV, DVD & HiFi listening in your home, or for people who have a hearing aid with a telecoil “T” setting. This product (although stand-alone) combines versatility and robustness, alongside sophisticated background noise control.

Product Features

• Standard Room Loop
• Excellent amplification
• Robust & Cost-effective

Product Contents

• Echo MegaLoop Amplifier

Product Specifications

• Distortion: <1%
• Audio Input: +20dB
• Microphone 1 Input: -20dB
• Microphone ‘P‘ Input: -30dB
• Frequency Response: 100Hz to 5.2khz
• Dimensions: 186 mm W x 50 mm H x 82 mm D
• Tone Control Effect: 20db range max – min (v/c middle)
• Power Supply: 12V DC, min. 1.5 amp (output Positive + Centre)
• Line Input: 2 Line-level Inputs; Phono Connectors, with gain control
• Microphone: 2 Microphone Inputs; 3.5mm mono/electret condenser
• Output: Output Current > 3A peak current; Loop resistance less than 1Ω
• Line Output: 1 Line-level Output; 3.5mm mono, Nominal Level = – 6dBu, output imp. 100ohm
