Ampetronic MLD9 MultiLoop Driver 9 (230V)
Recommended Retail Price
POA - 0191 414 4241
Require next-day delivery? Check out our shipping info
The Ampetronic MLD9 is a MultiLoop Driver ‘9’ (230V), with 2 x 9.2 arms for areas up to 3,300m2 – capable of driving a wide variety of Multiple Loop Configurations for the most challenging requirements. With an Ampetronic MultiLoop™ Low Loss design, the MLD5 will drive an area up to 3,300m2, or can be used to drive two Perimeter Looped areas of up to 1,300m2 each.
Designed to provide optimum efficiency and ample current for standard compliant field strength, coupled with unmatched voltage headroom to ensure crystal clear sound reproduction without clipping or distortion at practical loads. The flexibility of Ampetronic MLD units allows each output channel to drive separate loops, or two drive two overlaid loop patterns, with or without the selectable phase shift between the two channels.
Product Features
- AGC & Metal loss correction
- Up to 2 x 1,300m2 Perimeter Loops area coverage
- Up to 3,300m2 MultiLoop™ Low Loss area coverage
- Front inlet & rear exhaust fan cooling for true rack mount integration
- Active loop error monitoring & dual loop fault detection at start-up
- Space saving 1U rack mount unit, the most space efficient loop driver available
- Drives 2 output channels at 9.2ARMS each, featuring accurate and stable 90° phase shift
- Tested to, and compliant with: IEC 62489-1 induction loop amplifier performance standard
- Optimised for speech frequencies with unmatched intelligibility & capable of high quality musical reproduction
Product Applications
- Airports & railway stations
- Courts rooms & lecture Halls
- Classrooms & conference facilities
- Stadia, sports halls, cinemas & theatres
Downloads
If available, product downloads will appear here.
Data Sheet
For AmpetronicMLD9 in PDF format
